Product Description
The GAMDIAS ATLAS M3M Black introduces an immersive approach to compact desktop aesthetics, featuring a stunning three-sided columnless tempered glass panel layout. This premium dual-chamber micro-tower delivers a completely seamless, panoramic view of your interior components from the front, side, and top. Designed to optimize high-end hardware integration, it fully supports backside-connector (hidden-cable) motherboards to guarantee a completely cable-free visual workspace. Pre-equipped with three 120mm NOTUS M1 ARGB PWM fans and an innovative angled airflow system directed at the graphics card, the ATLAS M3M bridges ultra-clean styling with heavy-duty enthusiast thermal performance.
Specification |
Detail |
Brand |
GAMDIAS |
Series |
ATLAS Series |
Model |
ATLAS M3M |
Case Form Factor |
Micro-Tower |
Chassis Material |
SPCC Steel, ABS Plastic, & Tempered Glass |
Color |
Matte Black |
Motherboard Support |
Micro-ATX, Mini-ITX (Supports back-connect / hidden-connector boards) |
Pre-Installed Fans |
Side: 2 x 120mm NOTUS M1 ARGB PWM Reverse Intake FansRear: 1 x 120mm NOTUS M1 ARGB PWM Exhaust Fan |
Total Fan Capacity |
Up to 6 fans (Side: 2x 120mm, Bottom: 3x 120mm or 2x 140mm, Rear: 1x 120mm/140mm) |
Radiator Support |
Side: Up to 240 mm / Bottom: Up to 360 mm |
Expansion Slots |
5 |
Drive Bays |
1 x 3.5″ or 1 x 2.5″ (HDD Cage) + 2 x 2.5″ (SSD Mounts) |
Front/Side I/O Ports |
1 x USB 3.2 Gen 2 Type-C (10Gbps), 1 x USB 3.0, 1 x HD Audio, 1 x LED Control, 1 x Reset |
Pre-Installed Hub |
8-Port PWM & 5V 3-Pin ARGB Control Hub (4 ports utilized) |
CPU Cooler Clearance |
Up to 165 mm |
VGA / GPU Clearance |
Length up to 400 mm (Ready for next-gen enthusiast cards) |
PSU Clearance |
Length up to 160 mm (Bottom-mounted ATX) |
Window Panels |
Front, Left Side, and Top Premium Tempered Glass |
Product Dimensions (L x W x H) |
420 mm x 285 mm x 350 mm |
-
Breathtaking three-sided columnless glass architecture wraps across the front, side, and top panels for a seamless, completely unobstructed hardware display
-
Hidden-connector motherboard baseline compatibility lets you use back-plugging PCBs to route all primary power cables directly into the rear chamber
-
Three factory-installed NOTUS M1 ARGB PWM fans utilize optimized hydraulic cores to merge dynamic speed management with vibrant lighting sync
-
Specialized 8-port PWM and 5V addressable RGB control box unifies all thermal and light animations easily through a single main header interface
-
Advanced angled airflow design utilizes an offset fan configuration to scoop fresh intake air and throw it straight into your graphics card’s fans
-
Dual-chamber frame isolates the heat-heavy power supply and storage drives to the rear compartment, leaving the main viewing cabin clean and empty
-
Heavy-duty physical volume clearances accommodate premium graphics processing units up to 400mm long without experiencing chassis crowding
-
Ultra-fast peripheral interface features a high-bandwidth USB 3.2 Gen 2 Type-C panel port capable of 10Gbps high-speed data transfers
