BITFENIX WHISPER M 550W GOLD FULLY MODULAR

  • TYPE: Power Supply
  • SKU: 4712883216060
Brand New1 Year Warranty
$65.00
BITFENIX WHISPER 550W GOLD FULLY MODULAR
BITFENIX WHISPER 550W GOLD FULLY MODULAR
BITFENIX WHISPER 550W GOLD FULLY MODULAR
BITFENIX WHISPER 550W GOLD FULLY MODULAR
BITFENIX WHISPER 550W GOLD FULLY MODULAR
BITFENIX WHISPER 550W GOLD FULLY MODULAR
BITFENIX WHISPER 550W GOLD FULLY MODULAR
BITFENIX WHISPER 550W GOLD FULLY MODULAR
BITFENIX WHISPER 550W GOLD FULLY MODULAR
BITFENIX WHISPER 550W GOLD FULLY MODULAR

Notify me when BITFENIX WHISPER M 550W GOLD FULLY MODULAR - Default Title becomes available.

The BitFenix Whisper M 550W is an elite-tier, 80 Plus Gold certified power supply unit (PSU) engineered to deliver uncompromised electrical stability and near-silent operation. Designed for mid-range gaming rigs, compact workstations, and highly efficient daily computing setups, this power supply combines an advanced multi-rail topology with 100% industrial-grade Japanese components. Its fully modular framework and flat ribbon-style cabling maximize chassis airflow and clean cable management, making it an exceptional, high-reliability foundation for mainstream hardware configurations.

Form Factor / Type
Intel ATX 12V V2.4 / EPS 12V
Power Factor Correction
Active PFC (PF Value > 0.99)
+12V Rail Architecture
Dedicated Triple +12V Rails
MTBF / Reliability
> 100,000 Hours

Specifications

Model Name / SKU BitFenix Whisper M 550W / BWG550M (BP-WG550UMAG-7FM)
Form Factor / Type Intel ATX 12V V2.4 / EPS 12V
Maximum Wattage 550 Watts Continuous DC Output (at up to 50°C)
Efficiency Certification 80 PLUS Gold Certified (Up to 92% efficiency @ typical load)
Power Factor Correction Active PFC (PF Value > 0.99)
AC Input Range Full Range: 100V–240V AC / 8A / 47–63Hz
+12V Rail Architecture Dedicated Triple +12V Rails
Internal Topology LLC Resonant Topology with DC-to-DC Conversion
Capacitor Engineering 100% High-Performance Japanese Industrial 105°C Capacitors
Cooling Fan Layout 135mm Premium Fluid Dynamic Bearing (FDB) Fan
Cable Management 100% Fully Modular Ribbon Flat Cables
MTBF / Reliability > 100,000 Hours
Chassis Dimensions 160 mm (Depth) × 150 mm (Width) × 86 mm (Height)

Highlights

  • 80 PLUS Gold Efficiency Rating: Attains an outstanding 92% efficiency rating under typical system loads, minimizing utility grid power waste and internal thermal losses. It is fully optimized to meet strict modern energy-saving standards and works seamlessly with Intel Haswell C6/C7 sleep states.
  • Dedicated Triple-Rail +12V Design: Utilizes an intelligent multi-rail power layout partitioned for Motherboard/Peripherals (12V1), CPU (12V2), and GPU (12V3). Each independent rail features dedicated Over Current Protection (OCP) circuits to supply unthrottled energy safely without risking damage from cross-component failures.
  • Advanced LLC Resonant & DC-to-DC Topology: Implements a premium LLC resonant circuit switching architecture alongside separate DC-to-DC minor rail conversion stages (+5V and +3.3V). This structure ensures tight DC voltage regulation and remarkably low ripple noise for sensitive electronics.
  • 100% Industrial Japanese 105°C Capacitors: Loaded entirely with premium Japanese solid polymer and electrolytic capacitors. Rated to function reliably under intense 50°C system operating environments, they drastically extend operational lifespans and ensure rock-solid power delivery.
  • Premium Fluid Dynamic Bearing Fan: Houses a specialized silence-optimized 135mm Fluid Dynamic Bearing (FDB) cooling fan. The fluid dynamic architecture prevents physical metal-on-metal friction, significantly multiplying the fan's lifespan compared to standard sleeve-bearing alternatives.
  • Flat Ribbon-Style Modular Cabling: Features flexible, 18AWG thick all-black flat modular ribbon cables that detach completely. This allows you to plug in only the necessary power lines to maximize internal chassis airflow and maintain a professional, clutter-free aesthetic.
  • Industrial-Grade Safety Suite: Outfitted with robust, full-spectrum hardware guardrails: Over Current (OCP), Over Voltage (OVP), Under Voltage (UVP), Over Power (OPP), Short Circuit (SCP), Over Temperature (OTP), No Load Operation (NLO), and Surge & Inrush Protection (SIP).
Anchor your gaming configuration with the pristine power delivery of the BitFenix Whisper M 550W Gold Fully Modular Power Supply. Unifying an efficient 80 PLUS Gold circuit framework, a rock-solid dedicated triple +12V rail layout, high-end 105°C Japanese industrial capacitors, and an ultra-quiet fluid dynamic bearing fan profile, this continuous-power PSU delivers the ultimate combination of stable voltage output, clean modular cable management, and whisper-silent thermal control.
