DEEPCOOL PF600X 600W 800 PLUS BRONZE

  • TYPE: Power Supply
  • SKU: 6933412743941
Brand New1 Year Warranty
$65.00
DEEPCOOL PF600X 600W 800 PLUS BRONZE
DEEPCOOL PF600X 600W 800 PLUS BRONZE
DEEPCOOL PF600X 600W 800 PLUS BRONZE
DEEPCOOL PF600X 600W 800 PLUS BRONZE
DEEPCOOL PF600X 600W 800 PLUS BRONZE
DEEPCOOL PF600X 600W 800 PLUS BRONZE
DEEPCOOL PF600X 600W 800 PLUS BRONZE
DEEPCOOL PF600X 600W 800 PLUS BRONZE
DEEPCOOL PF600X 600W 800 PLUS BRONZE
DEEPCOOL PF600X 600W 800 PLUS BRONZE

Notify me when DEEPCOOL PF600X 600W 800 PLUS BRONZE - Default Title becomes available.

The DeepCool Gamer Storm PF600X is a high-efficiency, non-modular 600W power supply unit engineered to deliver stable, clean, and reliable energy to budget-to-mid-range gaming rigs and everyday multitasking workstations. Adhering strictly to the modern Intel ATX 2.52 design standard, this compact black enclosure features an advanced electrical architecture designed to suppress ripple noise and eliminate voltage deviations. Combining multi-agency bronze efficiency certifications with premium Japanese and Taiwanese internal filtration arrays, the PF600X provides the perfect combination of essential performance safeguards and long-term operating durability.

Form Factor / Type
ATX12V V2 .52
Continuous Power Output
600 Watts
Model Name / SKU
PF600X / R-PF600X-HD0B-JGUK
Mean Time Between Failures
40,000 Hours (MTBF)

Specifications

Model Name / SKU PF600X / R-PF600X-HD0B-JGUK
Form Factor / Type ATX12V V2 .52
Cabling Configuration Non-Modular / Custom-Molded Flat Black Sleeved Cables
Continuous Power Output 600 Watts
Efficiency Certifications 80 PLUS 230V EU Bronze / Cybenetics Bronze / PPLP 230V Bronze
Cybenetics Noise Level Cybenetics A 230V (Ultra-Quiet Performance)
Topology Architecture Active PFC + Double Forward + DC-to-DC Conversion
Capacitor Configuration Premium Taiwanese Solid + Dual Japanese Brand Electrolytic
Cooling Fan Engine 120mm Long-Life Hydro-Dynamic Bearing (HYB) Fan
Mean Time Between Failures 40,000 Hours (MTBF)
Dimensions (W x L x H) 150 mm x 140 mm x 86 mm

Highlights

  • Multi-Bronze Efficiency Standards: Validated by 80 PLUS, Cybenetics, and PPLP to secure an 88% energy efficiency rating at typical 50% system loads. This prevents unnecessary power grid draw and keeps internal heat production to an absolute minimum.
  • Intel ATX 2.52 DC-to-DC Topology: Engineered using a dual-stage EMI circuit, an active PFC setup, and double forward DC-to-DC conversion rails. This structural design enforces strict voltage tracking and provides excellent compatibility with modern processor power profiles.
  • Premium Taiwanese & Japanese Filtering: Fitted with premium Taiwanese solid and electrolytic bulk capacitors to preserve a power hold-up time ≥ 16ms under a heavy 75% system load. Crucial standby power lines are reinforced with dual Japanese brand electrolytic components, boasting a four-fold extended service lifespan over generic hardware.
  • Aerodynamic 120mm HYB Fan: Maintained by a 120mm Hydro-Dynamic Bearing (HYB) cooling fan running an optimized PCB flow-resistance layout. This long-life fan delivers up to a 30% longer service lifespan than sleeve models and operates continuously 24/7 in demanding 40°C scenarios while honoring a hushed Cybenetics A noise limit.
  • Stealthy Custom-Molded Cable Strands: Equipped with fixed, premium flat black sleeved cables designed by Gamer Storm. The flexible ribbons bend easily around chassis layout constraints, making behind-the-tray routing a clean experience while keeping the main chamber clear for airflow.
  • 8-Tier IC Safety Shield Matrix: Outfitted with an integrated industrial-grade protection circuit that constantly monitors system parameters. It guards against Over-Power (OPP), Over-Voltage (OVP), Short-Circuit (SCP), Over-Temperature (OTP), Over-Current (OCP), Under-Voltage (UVP), Surge & Inrush (SIP), and No-Load Operations (NLO).
  • Wide Voltage Adaptation Integration: Designed to protect systems connected to unstable power infrastructure by supporting a wide 180V–264V AC input operational profile. It is factory-tested to survive full operational loads under room temperatures even if a grid drops down to a 160V brownout sagginess, completely averting sudden system shutdowns.
Lay down a rock-solid, efficient, and well-protected foundation for your next mainstream PC build with the DeepCool Gamer Storm PF600X 600W 80 PLUS Bronze power supply. By matching multi-certified 88% efficiency with premium Japanese and Taiwanese hardware components, an ultra-quiet 120mm HYB cooling fan, and flat black cable management styling, this 600W power supply delivers the ultimate balance of long-term operational peace of mind and clean system aesthetics.
