GIGABYTE

GIGABYTE GEFORCE RTX 5060 TI 8GB GAMING OC - BLACK

  • TYPE: Graphics Card
  • SKU: 4719331356019
Brand New1 Year Warranty
$630.00

Notify me when GIGABYTE GEFORCE RTX 5060 TI 8GB GAMING OC - BLACK - Default Title becomes available.

The GIGABYTE GeForce RTX 5060 Ti GAMING OC Edition delivers elite next-generation performance wrapped in a bold, dark mech-warrior design. Powered by the advanced NVIDIA Blackwell architecture and packed with ultra-fast GDDR7 memory, this card comes factory overclocked to push high-refresh-rate 1080p and 1440p gaming to its absolute limits. Featuring an enhanced triple-fan WINDFORCE cooling system, customizable RGB lighting, and an integrated dual BIOS switch, the GAMING OC edition balances premium thermal dissipation with striking aesthetics for gaming enthusiasts.

Memory Size
8 GB
Interface
PCI Express 5.0 x16 (runs at x8)
Graphics Chipset
NVIDIA GeForce RTX 5060 Ti
Power Consumption (TDP)
180 W

Specifications

Brand GIGABYTE
Series GAMING OC Series
Model GV-N506TGAMING-OC-8GD
Graphics Chipset NVIDIA GeForce RTX 5060 Ti
Architecture Blackwell
Core Clock 2647 MHz (Reference: 2572 MHz)
CUDA Cores 4608
Tensor Cores 144 (5th Generation)
Ray Tracing Cores 36 (4th Generation)
Memory Size 8 GB
Memory Type GDDR7
Memory Bus 128-bit
Memory Speed 28 Gbps
Interface PCI Express 5.0 x16 (runs at x8)
Digital Max Resolution 7680 x 4320 (8K UHD)
Multi-Monitor Support Up to 4 displays
Video Outputs 1 x HDMI 2.1b, 3 x DisplayPort 2.1b
Power Consumption (TDP) 180 W
Recommended PSU 500 W
Power Connectors 1 x 8-pin PCIe
Card Dimensions (L x W x H) 300 mm x 130 mm x 50 mm
Slot Width 2.5 Slots

Highlights

  • Powered by the cutting-edge NVIDIA Blackwell architecture with native support for DLSS 4 neural rendering and advanced Multi Frame Generation
  • Dynamic WINDFORCE triple-fan cooling system utilizes alternate spinning Hawk Fans to boost airflow pressure and minimize turbulence
  • Integrated semi-passive 3D Active Fan design turns off the cooling fans during light use to guarantee a silent computing experience
  • Premium server-grade thermal conductive gel applied directly across critical VRAM and MOSFET components for improved long-term reliability
  • Futuristic mech armor styling with subtle RGB lighting effects customizable via the GIGABYTE CONTROL CENTER (GCC) software
  • Dual BIOS physical toggle switch allows for effortless switching between performance-driven OC mode and an ultra-quiet Silent profile
  • Reinforced protective backplate with an extended screen-cooling vent maximizes hot air dissipation through the heatsink
  • Ultra Durable components include lower ESR solid capacitors and metal chokes to optimize power delivery and extend hardware life
Unleash advanced framing power with the GIGABYTE GeForce RTX 5060 Ti GAMING OC Edition. Outfitted with 8GB of rapid GDDR7 memory, a robust triple-fan configuration, and factory-overclocked performance, it brings immersive ray tracing and smooth visuals to any modern gaming battle station.
